Electric Crawler Mini Dumper 500kg 1000kg Mini Track Dumper Moving Type Crawler Loader

Large Image : Electric Crawler Mini Dumper 500kg 1000kg Mini Track Dumper Moving Type Crawler Loader

Product Details:

Place of Origin:	Shandong, China
Brand Name:	HUAQI

Payment & Shipping Terms:

Minimum Order Quantity:	1 unit
Price:	$2,060.00/sets 1-19 sets

Contact Now

Electric Crawler Mini Dumper 500kg 1000kg Mini Track Dumper Moving Type Crawler Loader

Description

Applicable Industries:	Hotels, Garment Shops, Building Material Shops, Machinery Repair Shops, Manufacturing Plant, Food & Beverage Factory, Farms, Restaurant, Home Use, Retail, Food Shop, Printing Shops, Construction Works , Energy & Mining, Food & Beverage Shops, Advertising C	Showroom Location:	Indonesia, None
Condition:	New	Type:	Mini Loader
Moving Type:	Crawler Loader	Dimension(Long * Breadth * High):	1480 X 832 X 1344 Mm
Warranty:	1 Year	Machine Weight:	360 Kg
Hydraulic Cylinder Brand:	Eaton	Hydraulic Pump Brand:	Eaton
Hydraulic Valve Brand:	Eaton	Engine Brand:	YANMAR
UNIQUE SELLING POINT:	High Operating Efficiency	Power:	Other, 75 KW, 60 KW, 44.7 KW, 37 KW, 70 KW, 92 KW
Bucket Capacity:	270 L	Machinery Test Report:	Provided
Video Outgoing-inspection:	Provided	Marketing Type:	Ordinary Product
Warranty Of Core Components:	1 Year	Core Components:	Engine
Product Name:	Mini Dumper	Max. Operating Mass:	860 Kg
Transport Mass:	360 Kg	Pump:	Tandem Gear Pump (4cc X2) 3600rpm
Motor:	Disc Distribution Cycloid Motor (x2)	Working Pressure:	Max. 180 Bar
Hydraulic Flow:	28.8 L	Keyword:	Rubber Track Truck
Name:	Crawler Dumper Trucks	Key Words:	MINI Dumper

Product Description

Mini Track Dumper 500kg 1000kg Mini Dump Truck Electric Crawler Mini Dumper

Mini dump trucks, compact in size yet mighty in performance, boast several distinctive features. Their agile maneuverability allows access to tight spaces, enhancing efficiency in construction and landscaping tasks. With a robust chassis and durable components, they ensure reliability even in rugged terrains. Equipped with efficient engines, they offer impressive power-to-weight ratios, optimizing fuel consumption. Versatile in functionality, they can be adapted for various applications, from hauling materials to waste management. Additionally, ergonomic design features prioritize operator comfort and safety. Mini dump trucks stand as the epitome of compact yet powerful utility vehicles, catering to diverse industrial and commercial needs.

Discounted

Specification

Parameter	Value
Max. Operating Mass	860 kg
Transport Mass	360 kg
Overall (LxWxH)	2112 x 832 x 1344 mm
Transport Dimensions (LxWxH)	1480 x 832 x 1344 mm
Pump	Tandem gear pump (4cc x2) 3600rpm
Motor	Disc distribution cycloid motor (x2)
Working Pressure	Max. 180 bar
Hydraulic Flow	28.8 L
Motor Torque	645 Nm each at 180 bar
Driving	Hydraulic
Steering	Fully hydraulic / control valve
Forward	3.2 km/h
Reverse	3.2 km/h
Gradeability	15 degrees
Ground Clearance	71 mm
Engine Model	BTIGGS STRATTON XR950
Emission Accordance	EPA
Rated Power	6.5 HP / 3600rpm
Displacement	208 cc
Cylinder x Stroke	68.3 x 55.9 mm
Fuel Tank Volume	3.1 L
Oil Volume	0.6 L
Net Weight	16 Kg
Startup	Reversing & E-starter
Hopper Volume	270 L

FAQ

1.Q:Can the factory support mass production?

Can i purchase a customized sample first? A:Dear friends, our company can support mass production. It can mass produce 200+Mini Dumper in one month, can support customization, can customize colors and logos, etc. 2.Q:Can it be transported to my door?

I want to get my favorite Mini Dumper soon? A:Of course, my friend, but if your family is located very close to the port, we suggest that you can go directly to the port to transport your goods, so you can save a lot of money! If the distance is long, you can find an inland transportation company by yourself, and we can communicate with him; we can also find an agency for you, but the toll will be very high (not recommended)during transportation, we will not charge any intermediate fees and additional service fees other than freight. We just want you to get your favorite Mini Dumper earlier.

3.Q:How can i guarantee after-sales after i buy it? A:Dear friends, our machine has a one-year/1000h work warranty period. During this time, if there is any problem
