23HP Hydraulic Power Unit with 22L Fuel Tank Capacity and 155 bar Hydraulic Pressure

Large Image : 23HP Hydraulic Power Unit with 22L Fuel Tank Capacity and 155 bar Hydraulic Pressure

Product Details:

Place of Origin:	Shandong, China
Brand Name:	HUAQI

Payment & Shipping Terms:

Minimum Order Quantity:	1 unit
Price:	$4,500.00/sets 1-19 sets
Packaging Details:	wooden case

Contact Now

23HP Hydraulic Power Unit with 22L Fuel Tank Capacity and 155 bar Hydraulic Pressure

Description

Warranty:	1.5 Years	Showroom Location:	Canada, Turkey, Russia
Pressure:	Standard	Structure:	Standard
Weight:	160	Power:	313
Dimension(LWH):	860mm660mm800mm	Displacement:	12cm³
Pump Type:	SCREW PUMP	Maximum Flow Rate:	40L/min
Product Name:	Hydraulic Vane Pump	Start Mode:	Manual Pull / Electric Start (Optional)
Application:	Slurry Pumps	Engine:	Bailitong
Hydraulic Pressure:	155 Bar	Fuel Tank Capacity:	22 L
Engine Fuel Consumption Per Hour:	6 L	Hydraulic Tank Capacity:	18 L
System Type:	Open System	Keywords:	Hydraulic Small Electric Oil Pump

Product Description

Click here for more discounts

Our Hydraulic Power Station is equipped with the powerful Bailitong 18HP engine, providing reliable and efficient performance for a wide range of hydraulic applications. With two options for hydraulic flow rate - 1×26 lpm or 1×40 lpm - you can choose the configuration that best suits your specific needs. The hydraulic system operates at a pressure of 155 bar, ensuring optimal power for various tasks. Despite its robust capabilities, the machine remains compact and highly maneuverable, with dimensions of 860 mm in length, 660 mm in width, and 800 mm in height. Weighing 160 kg, it is designed for easy transport and operation. The Hydraulic Power Station is equipped with a 22-liter fuel tank, ensuring extended operation time without frequent refueling. The fuel consumption of the engine is an economical 6 liters per hour, optimizing fuel efficiency.

Specification

No.	Parameter	Value
1	Engine	Bailitong 18HP
2	Hydraulic Flow Rate	1×26 lpm / 1×40 lpm
3	Hydraulic Pressure	155 bar
4	Machine Length	860 mm
5	Machine Width	660 mm
6	Machine Height	800 mm
7	Machine Weight	160 kg
8	Fuel Tank Capacity	22 L
9	Engine Fuel Consumption per Hour	6 L
10	Hydraulic Tank Capacity	18 L
11	System Type	Open System

Company Profile

FAQ

1.Factory We are factory road roller manufacturer. 2. Warranty Our road roller have a one year quality warranty. 3.Markets We had sold our road roller to USA, Canada, Brizal, German, Spain, France, Italy, Dubai, Malaysia, India,Australia etc.. 4. Packing Full container loading with 6 pcs road roller, for LCL shipping, we'd pack the excavator with wooden packing. 5. Lead time For stocked road roller, we could ship the road roller within 7 days after payment, for customized road roller, we need some more days to customized them and shipping within 10 days.
