3.5 Ton Vibratory Road Roller with 74 L Vibration Frequency and 2-8km/h Travel Speed

3.5 Ton Vibratory Road Roller with 74 L Vibration Frequency and 2-8km/h Travel Speed
3.5 Ton Vibratory Road Roller with 74 L Vibration Frequency and 2-8km/h Travel Speed 3.5 Ton Vibratory Road Roller with 74 L Vibration Frequency and 2-8km/h Travel Speed 3.5 Ton Vibratory Road Roller with 74 L Vibration Frequency and 2-8km/h Travel Speed 3.5 Ton Vibratory Road Roller with 74 L Vibration Frequency and 2-8km/h Travel Speed 3.5 Ton Vibratory Road Roller with 74 L Vibration Frequency and 2-8km/h Travel Speed 3.5 Ton Vibratory Road Roller with 74 L Vibration Frequency and 2-8km/h Travel Speed

Large Image :  3.5 Ton Vibratory Road Roller with 74 L Vibration Frequency and 2-8km/h Travel Speed

Product Details:
Place of Origin: Shandong, China
Brand Name: HUAQI
Payment & Shipping Terms:
Minimum Order Quantity: 1 unit
Price: $8,500.00/sets 1-9 sets
Contact Now

3.5 Ton Vibratory Road Roller with 74 L Vibration Frequency and 2-8km/h Travel Speed

Description
Applicable Industries: Hotels, Garment Shops, Building Material Shops, Machinery Repair Shops, Manufacturing Plant, Food & Beverage Factory, Farms, Restaurant, Home Use, Retail, Food Shop, Printing Shops, Construction Works , Energy & Mining, Food & Beverage Shops, Advertising C Showroom Location: Canada, Russia, UAE, Tajikistan
Condition: New Type: Vibratory Roller
Travel Speed: 2-8km/h Grade Ability: 40%
Power: 4.8 Kw, 5.5 KW Dimension(L*W*H): 3830*1530*1920mm
Weight: 3500kg Warranty: 1 Year
Hydraulic Pump Brand: Huade Hydraulic Valve Brand: HYDAC
Engine Brand: CHANGCHAI UNIQUE SELLING POINT: EPA Engine
Drum Diameter: 950mm Drum: Double Drum Roller
Exciting Force: 55KN Machinery Test Report: Provided
Video Outgoing-inspection: Provided Marketing Type: Ordinary Product
Warranty Of Core Components: 1 Year Core Components: Motor, Pump, Engine
Product Name: Single Steel Wheel Paver Roller Name: 3.5t Road Roller
Engine Power: 39 HP Vibration Frequency: 74 L
Keywords: Wheel Roller Vibration Type: Automatic Clutch/Electromagnetic Clutch
Nominal Amplitude: 0.5mm Starting Method: Electric Start
Steel Wheel Width: 1200 Mm Key Words: Hydraulic Vibratory Road Roller

3.5 Ton Vibratory Road Roller with 74 L Vibration Frequency and 2-8km/h Travel Speed 0
Asphalt Road Roller Compactor Machine 3.5 Ton Asphalt Roller Brand New Vibratory Road Roller
The Single Steel Wheel Paver Roller is a sturdy and high-performing compaction machine designed for a wide range of road construction and compaction tasks. It is available with either a reliable Changchai or Changfa 390 engine, providing an impressive power output of 39 horsepower, ensuring exceptional performance and efficiency. Operating at speeds ranging from 2 to 8 km/h, the offers versatility and excellent maneuverability on various terrains. With an outstanding climbing ability of 40%, it can handle steep inclines and challenging working environments with ease. The paver roller is equipped with a nominal amplitude of 0.6 mm and operates at a vibration frequency of 45 Hz, delivering effective and consistent compaction results. The powerful excitation force of 55 KN ensures optimal compaction efficiency, achieving superior density for different construction materials.
Discounted
3.5 Ton Vibratory Road Roller with 74 L Vibration Frequency and 2-8km/h Travel Speed 1
Product Description
3.5 Ton Vibratory Road Roller with 74 L Vibration Frequency and 2-8km/h Travel Speed 2
3.5 Ton Vibratory Road Roller with 74 L Vibration Frequency and 2-8km/h Travel Speed 3
3.5 Ton Vibratory Road Roller with 74 L Vibration Frequency and 2-8km/h Travel Speed 4
3.5 Ton Vibratory Road Roller with 74 L Vibration Frequency and 2-8km/h Travel Speed 5
Specification
Parameter
Value
Parameter
Value
Name
LS-3500 Single Steel Wheel Paver Roller
Engine Brand
Changchai/Changfa
Travel Speed
2-8 km/h (Forward/Reverse)
Engine Model
390
Climbing Ability
40%
Engine Power
39 HP
Nominal Amplitude
0.6 mm
Vibration Frequency
45 Hz
Excitation Force
55 KN
Static Linear Load
90 N/cm
Fuel Tank Capacity
74 L
Hydraulic Oil Capacity
74 L
Vibration Mode
Hydraulic Vibration
Fuel Consumption Rate
≤ 310 g/kWh
Starting Method
Electric Start
Steel Wheel Width
1200 mm
Operating Weight
3500 kg
Steel Wheel Diameter
950 mm
Water Tank Capacity
200 L
Exterior Dimensions
3830*1530*1920mm
3.5 Ton Vibratory Road Roller with 74 L Vibration Frequency and 2-8km/h Travel Speed 6
Company Profile
3.5 Ton Vibratory Road Roller with 74 L Vibration Frequency and 2-8km/h Travel Speed 7
3.5 Ton Vibratory Road Roller with 74 L Vibration Frequency and 2-8km/h Travel Speed 8
Product packaging
3.5 Ton Vibratory Road Roller with 74 L Vibration Frequency and 2-8km/h Travel Speed 9
3.5 Ton Vibratory Road Roller with 74 L Vibration Frequency and 2-8km/h Travel Speed 10
Certifications
3.5 Ton Vibratory Road Roller with 74 L Vibration Frequency and 2-8km/h Travel Speed 11
FAQ
1.Q:Can the factory support mass production? Can i purchase a customized sample first? A:Dear friends, our company can support mass production. It can mass produce 200+Road roller in one month, can support customization, can customize colors and logos, etc. 2.Q:Can it be transported to my door? I want to get my favorite mini excavator soon? A:Of course, my friend, but if your family is located very close to the port, we suggest that you can go directly to the port to transport your goods, so you can save a lot of money! If the distance is long, you can find an inland transportation company by yourself, and we can communicate with him; we can also find an agency for you, but the toll will be very high (not recommended)during transportation, we will not charge any intermediate fees and additional service fees other than freight. We just want you to get your favorite Road roller earlier. 3.Q:How can i guarantee after-sales after i buy it? A:Dear friends, our machine has a one-year/1000h work warranty period. During this time, if there is any problem
